Cp 0022 Chicago Pneumatic Rock Drill
This product is not available in the selected currency.
In Stock
Backordered
Out of Stock
Description
Cp 0022 Chicago Pneumatic Rock Drill
| Particulars |  | CP 0022 |
| Weight | kg | 15 |
| Length | mm | 500 |
| Air consumption | l/s | 22 |
| Blows per minute | bpm | 2220 |
| Piston diameter | mm | 60 |
| Stroke length | mm | 44 |
| Rotation speed | rpm | 232 |
| Drill rate 2) | mm/min | 150 |
| Max drilling diameter | mm | 43 |
| Max drilling depth 3) | mm | 2400 |
| Air inlet | inch | 1/2" swivel |
| Muffler included | Â | No |
| Vibration level 3 axes (ISO 28927-10) 1) | m/s2 | 25,7 |
| Sound power level guaranteed (2000/14/EC) 1) Â Â Â | dB(A) | 116 |
| Sound pressure level (ISO 11203) 1) | dB(A) | 106 |
| Chuck size | mm | Hex 22x108 |
| Part number | Â | 8900002002 |
| Stock Code No | Â | Z0026439 |
