CP 0003 Chicago Pneumatic Backfill Tamper
This product is not available in the selected currency.
In Stock
Backordered
Out of Stock
Description
CP 0003 Chicago Pneumatic Backfill Tamper
| Particulars | Â | CP 0003 |
| Weight | kg | 13,6 |
| Length | mm | 1320 |
| Body diameter | mm | 22 |
| Butt size | mm | 127 |
| Air consumption | l/s | 8,4 |
| Blows per minute | bpm | 800 |
| Air inlet | inch | 1/2" NPTF |
| Vibration level 3 axes | m/s2 | 32,3 |
| (ISO 20643) 1) | ||
| Sound power level | dB(A) | 108 |
| guaranteed (2000/14/EC) 1) | ||
| Sound pressure level (2000/14/EC) 1) Â Â Â | dB(A) Â | 95 |
| Sound power uncertainty value K | dB(A) | 3 |
| Valve type |  | Simplate Valve   |
| Bore and stroke | mm | 36,5x152 |
| Part number (at 6 bar) | Â | T019307 |
| Stock Code No. | Â | Z0010890 |
