CP 0004 Chicago Pneumatic Backfill Tamper
This product is not available in the selected currency.
In Stock
Backordered
Out of Stock
Description
CP 0004 Chicago Pneumatic Backfill Tamper
| Particulars | Â | CP 0004 |
| Weight | kg | 19 |
| Length | mm | 1270 |
| Body diameter | mm | 25 |
| Butt size | mm | 160 |
| Air consumption | l/s | 13 |
| Blows per minute | bpm | 780 |
| Air inlet | inch | 1/2" NPTF |
| Vibration level 3 axes | m/s2 | 44,8 |
| (ISO 20643) 1) | ||
| Sound power level | dB(A) | 109 |
| guaranteed (2000/14/EC) 1) | ||
| Sound pressure level (2000/14/EC) 1) Â Â Â | dB(A) Â | 94 |
| Sound power uncertainty value K | dB(A) | 3 |
| Valve type |  | Ring valve   |
| Bore and stroke | mm | 57x152 |
| Part number (at 6 bar) | Â | T022292 |
| Stock Code No. | Â | Z0021451 |
