10" DTH Hammer - VD10S x 225
This product is not available in the selected currency.
In Stock
Backordered
Out of Stock
Description
10" High Pressure DTH Hammer -Â VD10S x 225
Vikay is a global supplier of 10" High Pressure DTH Hammer Model VD10S x 225Â from India.

Â
Technical Details Â
| Model | VD10S x 225 |
| Outer Diameter | 225mm  (8.85") |
| Hammer Length | 1220mm (48") |
| Hammer Weight | 218kg  (480 lbs) |
| Coupler Thread Size    | 6 5/8†API | Reg Pin |
Air Consumption, cmfÂ
| 150psi   | 250psi   | ||
| Min   | Max   | Min   | Max   |
| 650 | 1080 | 1230 | 1690 |
Air Consumption, m3/min
| 10 bar | 18 bar | ||
| Min   | Max   | Min   | Max   |
| 18.5 | 30.6 | 35 | 47.5 |
Â
| Bit Shank |
| SD-6 |
| No Foot Valve Required    |
| Suitable Bit Size |
| 8" To And Above |
Since aprovement are made from time to time, the illustration and specifications are subject to change without notice
